TVS-675-8G-US QNAP 8-Bay Desktop NAS/iSCSI/IP-SAN 2.5 GHz ZhaoXin KX-U6580 8-core 8GB RAM - No HDD

Features:

• Up to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE ports
• Install high-performance M.2 PCIe NVMe Gen 3 x1 SSDs or economical SATA 6Gb/s SSDs in the dedicated SSD slots for caching with improved random I/O or high-performance storage pools
• Two PCIe Gen 3 slots allow for installing 2.5/5/10GbE adapters, QM2 cards, or QXP storage expansion cards
• 4K media playback and real-time transcoding; directly output videos to an HDMI 2.0 display (up to 4K @60Hz)
• Supports storage for virtualization; hosts multiple virtual machines and containers to run a wide range of applications on one NAS device
• Flexibly scale the total storage capacity to match business growth by connecting QNAP expansion enclosures

Powered by the x86 architecture Zhaoxin KaiXian KX-U6580 8-core processor, the TVS-675 provides businesses with a modern 2.5GbE NAS solution to tackle everyday tasks like file backup/restore, and to boost team collaboration with higher productivity. Besides hardware advantages with built-in M.2 SSD slots for cache acceleration and PCIe expansion, the TVS-675 supports abundant business and media applications (including snapshot protection, virtual machines, cloud storage gateways, 4K HDMI display, and real-time transcoding) alongside expandable storage capacity and install-on-demand apps, making it a cost-effective and reliable data storage and media NAS.

Specifications

• CPU - ZhaoXin KX-U6580 8-core 2.5GHz processor
• CPU Architecture - 64-bit x86
• Graphic Processors - ZhaoXin C-960 Graphics
• Floating Point Unit - Yes
• Encryption Engine - Yes (AES-NI)
• Hardware-accelerated Transcoding - Yes
• System Memory - 8 GB SODIMM DDR4 (1 x 8 GB)
• Maximum Memory - 64 GB ( 2 x 32 GB)
• Memory Slot - 2 x SO-DIMM DDR4
• Flash Memory - 5GB (Dual boot OS protection)
• Drive Bay - 6 x 3.5-inch SATA 6Gb/s, 3Gb/s
• Drive Compatibility - 3.5-inch bays: 3.5-inch SATA hard disk drives, 2.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
• Hot-swappable - Yes
• M.2 Slot - 2 x M.2 2280 PCIe Gen 3 x1 or SATA 6Gb/s slots
• SSD Cache Acceleration Support - Yes
• 2.5 Gigabit Ethernet Port (2.5G/1G/100M) - 2
• 5 Gigabit Ethernet Port (5G/2.5G/1G/100M) - Optional via an adapter
• 10 Gigabit Ethernet Port - Optional via an adapter
• Wake on LAN (WOL) - Yes
• Jumbo Frame - Yes
• PCIe Slot - 2, Slot 1: PCIe Gen 3 x4, Slot 2: PCIe Gen 3 x4
• USB 3.2 Gen 1 port - 1
• USB 3.2 Gen 2 (10Gbps) Port - 2 x Type-A
• HDMI Output - 1, HDMI 2.0 (up to 3840 x 2160 @ 60Hz)
• Form Factor - Tower
• LED Indicators - HDD 1-6, Status, LAN, USB, M.2 SSD 1-2
• Button - Power, Reset, USB Copy
• Dimensions (HxWxD) - 188.2 × 263.9 × 280.8 mm
• Weight (Net) - 6.2 kg
• Weight (Gross) - 7.67 kg
• Operating temperature - 0 - 40 °C (32°F - 104°F)
• Storage Temperature - -20 - 70°C (-4°F - 158°F)
• Relative Humidity - 5-95% RH non-condensing, wet bulb: 27 ̊C (80.6 ̊F)
• Power Supply Unit - 250W, 100-240V AC, 50/60Hz, 3.5A
• Power Consumption: HDD Sleep Mode - 41.897 W
• Power Consumption: Operating Mode, Typical - 60.794 W
• Fan - 3 x 80mm, 12VDC
• Sound Level - 20.2 db(A)
• System Warning - Buzzer
• Kensington Security Slot - Yes
• Max. Number of Concurrent Connections (CIFS) - with Max. Memory - 2000
