V3518FIC-MPYIR Computar 1.1" C-Mount 35mm F1.8 12MP IR Corrected Manual Iris Lens
- Brand: Computar
- Model: V3518FIC-MPYIR
- SKU: V3518FIC-MPYIR
- MPN: V3518FIC-MPYIR
$960.00
Features:
- For Machine Vision and ITS Applications
- 35mm Fixed Lens
- 12 Megapixel
- C Mount
- Smallest 1.1” format lens for > 10MP Lens in the industry
- F 1.8
- IR Corrected
- 3.45µm pixel size
- Lightweight
- Vibration resistance up to 5G
The MPY Series supports 1.1” sensor format at 12 Megapixel resolution in a C-mount lens. The MPY Series combines high performance optics with a variety of common focal lengths for maximum application flexibility.
Specifications
- Model No - V3518FIC-MPYIR
- Focal Length - 35mm
- Max. Aperture Ratio - 1:1.8
- Max. Image Format - 14.2mm x 10.4mm(φ17.6mm）
- Operation Range
- Iris - F1.8 ‐ F16C
- Focus - 2m ‐ lnf.
- Zoom - -
- Control
- Iris - Manual
- Focus - Manual
- Zoom - -
- Angle of View
- D 1.1 type - 27.4°
- H 1.1 type - 22.3°
- V 1.1 type
- 1 type
- D - 25.1°
- H - 20.2°
- V - 15.2°
- 2/3 type
- D - 17.4°
- H - 14.0°
- V - 10.5°
- Effective Lens Aperture
- Front - φ23.9mm
- Rear - φ17.8mm
- Back Focal Length - 14.2mm
- Flange Back Length - 17.526mm
- Mount - C-Mount
- Filter Size - M40.5 P=0.5
- Dimensions - φ46mm × 48.8mm
- Weight - 153g
- Operating Temperature - -10°C ‐ +50°C
