TS-h2287XU-RP-E2336-32G-US QNAP 22-Bay Rackmount NAS 2.9 GHz Intel Xeon E-2336 6-core 32GB RAM - No HDD

Features:

• Combines the advantages of high-capacity HDD and high-performance SSD. Supports SSD caching to boost IOPS performance
• Dual 10GBASE-T and dual 2.5GbE high-speed connectivity enhances virtualization, intensive file access, and large backup/restoration tasks
• Install 10/25GbE adapters, QM2 cards, or Fibre Channel cards to increase application performance
• Supports virtualization storage and hosting virtual machines and containerized apps
• Optimized for business-class backup, including Google Workspace and Microsoft 365 data, and VMware and Hyper-V virtual machines
• Realizes hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud

Specifications

• CPU - Intel Xeon E-2336 6C 12T 2.9GHz, up to 4.8GHz
• CPU Architecture - 64-bit x86
• Floating Point Unit - Yes
• Encryption Engine - Yes (AES-NI)
• System Memory - 32 GB ECC DDR4 (2 x 16 GB)
• Maximum Memory - 128GB (4 x 32 GB)
• Memory Slot - 4 x ECC UDIMM DDR4
• Flash Memory - 5GB (Dual boot OS protection)
• Drive Bay - 22 (16 x 3.5-inch SATA + 6 x 2.5-inch SATA)
• Drive Compatibility
  • 3.5-inch bays: 3.5-inch SATA hard disk drives, 2.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
  • 2.5-inch bays: 2.5-inch SATA solid state drives
• M.2 Slot - Optional via a QM2 PCIe adapter
• SSD Cache Acceleration Support - Yes
• GPU pass-through - Yes
• 2.5 Gigabit Ethernet Port (2.5G/1G/100M) - 2 (2.5G/1G/100M)
• 10 Gigabit Ethernet Port - 2 x 10GBASE-T (10G/5G/2,5G/1G/100M)
• PCIe Slot - 3 (2 x Gen4 x4 +1 x Gen 4 x8)
• USB 3.2 Gen 2 (10Gbps) Port - 4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps
• Form Factor - 3U Rackmount
• LED Indicators - Status (Green/Red), LAN (Green), USB (Blue), HDD status (Green/Red)
• Buttons - Power, Reset
• Dimensions (HxWxD) - 5.24 × 19.02 × 24.8 inch
• Weight (Net) - 34.48 lbs
• Weight (Gross) - 48.68 lbs
• Operating Temperature - 0 - 40 °C (32°F - 104°F)
• Storage Temperature - -20 - 70°C (-4°F - 158°F)
• Relative Humidity - 5~95% RH non-condensing, wet bulb: 27°C (80.6°̊F)
• Power Supply Unit - 2 x 550W CRPS PSU
• Fan - 3 x 60mm + 1 x 80mm, 12VDC

TS-h2287XU-RP-E2336-32G-US Specifications PDF
